JIMS Pinion gear BTl77-89 black (GB)

Artikelnummer: ZO234906-GB
Kategorie: ZO-ARTIKEL-ENGLAND
Hersteller: JIMS

JIMS Pinion gear BTl77-89 black. | Item condition: NEW

189,95 €

inkl. 19% USt. ,

Auswahl Steuerzone / Lieferland

Knapper Lagerbestand
Lieferzeit: 8 - 9 Wochen (DE - Ausland abweichend)

Bei diesem Artikel ist die Stückzahl teilbar (z. B. 0,5).

Beschreibung

Pinion gears are available to fit Big Twin engines from 1937 thru 1989. These high quality gears are carefully machined, heat-treated and then finish ground. If the stock gear is unmarked and the size is unknown we recommend that you order a gear in the middle of the tolerance range. These sizes were used more often and should provide adequate gear clearance under most circumstances. Note: Gear sizes for 1954 thru 1989 are listed from biggest to smallest. This color coding sequence is identical to stock Harley-Davidson color coding for the late 1977 thru 1989 models. For the 1954 thru early 1977 models there was only one size available from Harley-Davidson, Jims and S&S issued their own color coding for these pinion gears. Sizes are given measured over .105" pins.
